99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component

Certification
China suzhou jingci super hard materials co.,Ltd certification
I'm Online Chat Now

99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component

99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component
99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component

Large Image :  99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component

Product Details:
Place of Origin: Suzhou China
Brand Name: Suzhou Jingci
Certification: REACH Certificate; ISO9001-2015
Model Number: JC-2-06
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: carton box 210mm*200mm*103mm
Delivery Time: 5-8 workdays
Payment Terms: L/C, T/T, D/P, D/A, L/C, Western Union
Supply Ability: 5000 pcs

99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component

Description
Material: 99% Al2O3 Gross Density: 3.8-3.9g/g/cm^3
Flexural Strength: 420 Mpa (Psi*103) Young’s Modulus (dynamic)/Elasticity Modules: 340 Gpa
Thermal Expanding Coefficient: 7.8 (1x10^-6/℃) Acid Resistance: Mg/cm^2 ≤0.7
High Light:

zirconia alumina ceramic

,

engineering ceramics

99% Alumina Ceramic Parts Corrosion Resistance Anti-abrasion Automobile Component



Alumina ceramics is a non-organic material with much higher hardness than metallic parts. Because of the universal existence of aluminum and oxygen, the price of alumina material maintain a comparatively lower price than other materials. Usually at room temperature the alumina powder with bonding agent is molded into solid green bodies with expected dimensions. Then the green bodies are sent into a hot tunnel stove to be fired, which process is known as sintering. After sintering, alumina ceramic parts will achieve its typical material properties such as minimal thermal expansion, excellent thermal shock behavior, striking temperature resistance, low thermal conductivity, high corrosion resistance and so on.



The gear-type oil pump installed in a passenger car, or household car, need to transfer or circulate lubricating oil ceaselessly under conditions involving high temperature and speed. That requires the pump work stable and well without leakage of oil. The pump components like gear, pressure relief valve with crescent shape, made of alumina ceramic, can resist wear and maintain its original dimensions, always keeping the gear pump work in good condition. At the same time,

They can bear comparatively high temperature change with little thermal expansion.



Suzhou Jingci Super Hard Materials Co., Ltd, (here after referred to as Jingci and whose website is www.fineceram.com) has been in the research and production or technical ceramic parts for nearly 20 years, and has been a A-grade supplier for foreign customers who produce car parts for famous car manufacturers.

Jingci will make continuous efforts to provide fine ceramic solution for customers around the world, whose visit, guidance and win-win cooperation are warmly welcome.
