Corrosion Resistance Alumina 99% 88HRA Ceramic Pump Seal

Corrosion Resistance Alumina 99% 88HRA Ceramic Pump Seal
Corrosion Resistance Alumina 99% 88HRA Ceramic Pump Seal

Large Image :  Corrosion Resistance Alumina 99% 88HRA Ceramic Pump Seal

Product Details:
Place of Origin: Suzhou China
Brand Name: Jingci
Certification: RoHS
Model Number: JCMF007
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: carton box 225mm*215mm*225mm
Delivery Time: 5-8 workdays
Payment Terms: L/C, T/T
Supply Ability: 30000pcs per 45 days

Corrosion Resistance Alumina 99% 88HRA Ceramic Pump Seal

Description
Name: Ceramic Pump Seal Material: Alumina
Feature: Corrosion Resistance Density: Alumina 3.7-3.9g/cm^3; Zirconia ≈6g/cm^3; Silicon Carbon ≈3.14g/cm^3
Vickers Hardness: Alumina 1800-2000 HV; Zirconia ≈1300 HV; Silicon Carbon ≈2500HV Fracture Toughness: Alumina ≈5 (Mpa M1/2) ; Zirconia 7 (Mpa M1/2)
Compressive Strength: Alumina >3200 (Mpa Psi*103); Zirconia ≈3900 (Mpa Psi*103);Silicon Carbon 2200 (Mpa Psi*103) Thermal Expending Coefficient: Alumina 7.8-8.2 (1*10^-6/℃);Silicon Carbon ≈4.5 (1*10^-6/℃)
High Light:

88HRA Ceramic Pump Seal

,

99% Ceramic Pump Seal

,

88HRA silicon carbide mechanical seal

Ceramic Seal Part 99% Alumina Ceramic Mechanical Spare Part Anti-abrasion





Advantages

● High wear resistance
● High corrosion resistance
● High-temperature resistance
● Dimensional stability and aging resistance
● Excellent sliding properties (tribology)
● Biocompatibility (for use in hygiene and the food and beverage industry)



Properties:



Powerful interatomic bonds endows zirconia ceramics not only with high hardness and wear resistance, but also a resistance to corrosion. Usually it has less hardness and brittleness than that of alumina ceramic, but has more elasticity, which means it is not as brittle as alumina ceramic. If hardness is not so exacting, zirconia parts are a good choice to be applied.



Detailed Product Description

Ceramic 95%
  Alumina
Fundamental properties High hardness, good wear resistance under abrasion,low electrical conductivity,good value for money
Main component 95% Al2O3
Gross density 3.7g/cm^3
Flexural Strength 400 Mpa (Psi*103)
Compressive Strength 3100Mpa (Psix103)
Fracture Toughness 5 Mpa m1/2
Young’s Modulus (dynamic)/Elasticity Modules 300 Gpa
Vickers Hardness 1500-2200 HV
Thermal Conductivity 28 W/mK
Coefficient of Linear Expansion
(20–400°C)
7.5 10^–6 K–1
Maximum Operating Temperature 1400 ℃
Thermal Expanding Coefficient 7.5 (1x10^-6/℃)
Thermal Shock Resistance 250℃ Tc
Disruptive Strength KV/mm,DC ≥20
Acid Resistance mg/cm^2 ≤0.7
Alkali Resistance mg/cm^2 ≤0.2
Wear Resistance g/cm^2 ≤0.1
Dielectric Strength 9.0 εr(20℃ ,1MHz)
Dielectric Constant 9.2 1MHz 25°
Tensile Strength 51KN
Volume Resistivity >10^15 100°
Water Absorption 0
Specific Heat Capacity 0.78x10^3 J/(kg.K)



Advantages of zirconia parts:



·High wear, heat, pressure, and chemical attack resistance (gas and liquids)

·Extreme hardness

·Excellent electrical insulation

·Relatively lightweight



About Us



Suzhou Jingci Super Hard Materials Co., Ltd has specialized in precision ceramics for more than twenty years and has rich experiences in designing and developing technical ceramic solutions for a wide variety of applications. Jingci has the capability to provide customers with expertise to make sure the best design and materials are made for their specific application and needs
